2014年12月21日星期日

Ph10mm 1R semi-outdoor led screen modules

APOLLOMI Ph10mm 1Red semi-outdoor led screen modules parameter

  • Pitch size(mm) 10mm
  • Resolution(pixel/M2) 10000
  • Pixel composition 1R
  • Led type(DIP) 546
  • Module size(mm) 320X160
  • Module resolution(dots) 32X16
  • Cabinet size(mm) 1280X960
  • Cabinet resolution(dots) 128X96
  • Drive mode(scan) Constant Current

APOLLOMI outdoor full color led screen modules

2014年12月17日星期三

F5.0-Ph7.62mm R/G matrix dot led screen module

APOLLOMI F5.0-Ph7.62mm Red/Green matrix dot led screen module parameter
  • Pitch size(mm) 7.62mm
  • Resolution(pixel/M2) 1722
  • Pixel compostion 1R1G
  • led type(matrix) 1588
  • Module size(mm) 488X244
  • Module resolution(dots) 64X32
APOLLOMI F5.0-Ph7.62mm Red/Green matrix dot led screen module front
APOLLOMI F5.0-Ph7.62mm Red/Green matrix dot led screen module back

APOLLOMI F5.0-Ph7.62mm Red/Green matrix dot led screen

APOLLOMI Certificate
APOLLOMI Factory
APOLLOMI Modules Packing
APOLLOMI Products

2014年12月11日星期四

F3.75-Ph4.75mm Red/Green matrix dot led screen

APOLLOMI F3.75-Ph4.75mm Red/Green matrix dot led screen module parameter
  • Pitch size(mm) 4.75mm
  • Resolution(pixel/M2) 44321
  • Pixel compostion 1R1G
  • led type(matrix) 1388
  • Module size(mm) 304X152
  • Module resolution(dots) 64X32
  • Drive mode(scan) Constant Voltage
APOLLOMI F3.75-Ph4.75mm Red/Green matrix dot led screen module front
APOLLOMI F3.75-Ph4.75mm Red/Green matrix dot led screen module back
APOLLOMI F3.75-Ph4.75mm Red/Green matrix dot led screen

2014年12月10日星期三

How to assembly led sign screen DIY


How to assembly led sign screen DIY

How to assembly led
How to assembly led sign screen DIY sign screen DIY

2014年12月9日星期二

LED Display solution

LED Display solution
LED display will be widely used in sports stadiums, cities and public square, transportation,
corporate image promotion, advertising and other applications. Viewing distance of the sports
venues, the environment, high brightness, LED display can only meet this special requirement, to
ensure that viewers get clear, sharp color images, as the audience's visual enjoyment. In public
places, indoor and outdoor LED display shows the dynamics of social information and pictures so
that people always feel the pulse beat of the community. Information as a public transport one of
the best means to display information, LED display will be at the airport, train stations, highways,
subway, light rail and other cities have a go. As a large size and high brightness of full-color
display, LED in the street, commercial plaza, tall buildings, parks, shopping centers become an
important commercial choice.
To maintain system reliability, on-site preventive maintenance and are very important. In addition,
the strong dust and water resistant simulation designed to withstand harsh outdoor environments.
For fixed installation, the module can be placed in specific installation requirements in accordance
with custom solid structure, form a whole.
In parts procurement, manufacturing and product design process application "overall quality"
management technology for the production of high-quality public goods and to protect the user's
long-term investment to provide a guarantee. Built-in PC to the module with the intelligence and
processing stability, built-in thermal management module to make products with higher quality
and longer life.
Modular design, circuit connectivity into different modules, each module requires only minimal
contact between the can greatly improve system stability and reliability. Display part is distributed
scanning technology, display is divided into different units, independent scanning, each unit
synchronization between the signals, indicating stability of the greatly increased.
Indoor and outdoor LED screen brightness and different levels of protection
Outdoor LED display shows the high brighter than indoor and outdoor LED displays typical
5,000-6,000 nits brightness, indoor LED display is 2,000 nits. Outdoor high brightness to a variety
of environmental conditions, even direct sunlight can be seen, the Office of the type LED display
also heat, rain, snow, etc.. Outdoor, LED display with cold, water, dust and cooling functions.

2014年12月8日星期一

F3.0-Ph4mm R/G matrix dot led screen modules

APOLLOMI F3.0-Ph4mm Red/Green matrix dot led screen module parameter

  • Pitch size(mm) 4mm
  • Resolution(pixel/M2) 62500
  • Pixel compostion 1R1G
  • led type(matrix) 1288
  • Module size(mm) 256X128
  • Module resolution(dots) 64X32
  • Drive mode(scan) Constant Voltage
APOLLOMI F3.0-Ph4mm Red/Green matrix dot led screen module back
APOLLOMI F3.0-Ph4mm Red/Green matrix dot led screen module front
